english 17
• IfasecondPersonisatthecircularsawbenchtoremove
cut workpieces, the machine must be equipped with a
tableextension.Thesecondpersonmayonlystandatthe
removalendofthetableextension.
• Fit only sharp, crackfree and undistorted circular saw
blades.
• Circularsawbladesmadeofsuperhighspeedsteelmust
not be used.
• Safetydevicesonthemachinemustnotbedismantledor
put out of action.
• The splitting wedge is an important safety feature. The
workpiece is fed through the splitting wedge, which
prevents the cut from closing behind the saw blade and
also prevents the workpiece from kicking back.
• AlwayslowertheprotectiveCoverovertheworkpiecefor
each operation.
• The cowl must stand horizontally above the saw blade
during all working procedures
•Alwaysusethepushstickforlongitudinalcuttingofnarrow
workpieces of less than 120 mm.
• Alwaysstopthemachineanddisconnectthemainsplug
before remedying faults or removing jammed pieces of
wood.
• Replacethebladeslotinsertifitisdamaged.Disconnect
the mains plug!
• Wear only closetting clothes. Remove rings, bracelets
and other jewelry.
• Payattentiontotherotationaldirectionofthemotorand
toolSeeElectricalConnection.
• Cleaning,changing,calibrating,andsettingofthemachine
may only be carried out when the motor is switched off.
Pullthepowersupplyplugandwaitfortherotatingtoolto
completely stop.
• Switchthe machineoffand pull power supply plug when
rectifying any malfunctions
• Forallworkingproceduresthemachinemustbeconnected
to a scheppach Dust extractor. Observe instructions for proper
use.
•Whenworkingonthemachine,allsafetymechanismsand
Coversmustbemounted.
• Circularsawbladesmadefromsuperspeedsteelmaynot
be used.
• The splitting wedge is an important safety feature. The
workpiece is fed through the splitting wedge, which
prevents the cut from closing behind the saw blade and
also prevents the workpiece from kicking back.
• Note the thickness of the splitting wedge See gures
stamped into the splitting wedge. The splitting wedge may
not be thinner than the saw blade and not thicker than
cutting joint width.
• Before the machine is put into operation it must be
connectedtoadustextractorwithaexible,nonammable
suction hose. The suction should switch on automatically
when the machine is switched on.
• Whenleavingtheworkplace,switchthemotoroff.Pullthe
power supply plug.
• Cutofftheexternalpowersupplyofthemachineorplant
evenifonlyminorchangesofplaceareenvisaged.Properly
reconnect the machine to the supply mains before
recommissioning.
• Connectionand repair workon theelectrical installation
may be carried out by a qualified electrician only.
• Allprotection andsafety devicesmustbereplacedafter
completing repair and maintenance procedures.
•Payattentiontoansufcientilluminationofthe
workplace.
•Proofthebrakingtimetillthesawbladestoppsdaily.
Itmustnotbelongerthan10seconds,otherwisedonot
continue working.
•Alwayswearearprotectionandprotectionglassesduring
working
•Weargloveswhenyouchangethesawblade
•Powerdownthemachinewhenyoucleanit
•Operating conditions: Do not use the machine outside only
inside in closed rooms
•Store conditions: humidity should not be under 90% and
not condensed
•Safebigworkpiecesofcanting
Use only as authorized
• The machine corresponds to the valid EC guideline.
• The scheppach ts 4020 circular sawbench is defined as a
machine in accor- dance with EN 1870-1.
•Fortransportingthemachinewithintheworkshopareause
the scheppach wheel assembly(accessory)
• Theworkingpositionistothefrontofthemachineeither
to the right or the left sawblade.
• Themachiningrangeandsurroundingareasofthemachine
must be clear of interfering foreign mat- ter to prevent
accidents occurring.
• Workpiecesmustbecompletelyfreeofforeignobjects,i.e.
nails or screws.
• Before the machine is put into operation it must be
connectedtoadustextractorwithaexible,nonammable
suction hose. The suction should switch on automatically
when the machine is switched On.
•Usethescheppachdustextractorha3200orha2600to
removematchwoodorsawdust.Thevacuumsupportow
rate must be 20 mls. Subat- mospheric pressure
1200Pa.
• Thescheppach automatic switching unit is avai- lable as a
special accessory.
TypALV2
Art.Nr.79104010230V150Hz
TypALV10
Art.Nr.79104020400V150Hz
Thevacuumexhaustunitautomaticallyswitchesonaftera
2-3 second delay after the machine tool is turned On. This
avoids overloading the circuit fuse.
Afterturningoffthemachinetool,thevacuumexhaustunit
remains on for an additional 3 - 4 seconds and is then
automatically switched off. Remaining dust is thereby
removed by vacuum exhaust, as required by German
regulations governing hazardous materials. This results in
savings in electricity consumption and reduces noise
levels, as the vacuum exhaust unit is on only during
machine tool operation.
Forworkincommercialspaces,thescheppachdustextractor
rg 4000 must be used. Do not remove or shut off vacuum
exhaustsystemsordustremoverswhilemachinetoolsare
operating.
• Thescheppachcircularsawbenchisdesignedexclusively
for the machining of wood and materi- als similar to wood.
Only original scheppach tools and accessories may be
used.Usetherequiredsawbladeinaccordancewiththe
EN8471normdependingonthetypeofcutandtypeof
wood(solidwood,plywoodorchipboard).Pleaseobserve
the scheppach ,,Special Tool Accessories“(page18).
