english 19
sawblade 7986 3001
Speciallownoisesawblade,hardenedmetaltippedfor
plastic coated furniture boards.
Dimensions:
Total Ø mm 300
Bohrung Ø mm 30
No.ofteeth 60Z
sawblade 5100 5501
Universaltrimmingbladeforsoftandhardwood.
Dimensions:
Total Ø mm 300
Bore Ø mm 30
No.ofteeth 28WZ
Scoring sawblade 5472 0313
Hardened metal sawblade for scoring plastic coated
furniture boards.
Dimensions:
Total Ø mm 120
Bore Ø mm 20
No.ofteeth 26Z
Technical data
Dimensions:
general length mm 1100
totallengthwithtableextension mm 1400
totalwidth   mm 760
total height mm 1110
tablesize   mm 805x680
table height mm 850
circularsawbladeØmax.  mm 315
circular sawblade Ø min. mm 250
cut height 90° mm 110
cutheight45°   mm 77
sawblade adiustment ranae mm 110
rotaryspeed   1/min. 4000
cuttingspeed   m/sec. 66
scoring sawblade Ø mm 120
scoringsawbladerotaryspeed 1/min. 8000
cuttingspeedscoring  m/sec. 50
parallel stop longitudina mm 800
parallelcutmax.width  mm 390
parallel cut width with table width
extensionfoldable  mm 1100
angling fence 0-60°
anglingfenceguide  mm TProl
Cut width 90“ angular cut:
withCross/mitregauge  mm 270
with sliding table carriage 1400 mm 900
with sliding table carriage 2000 mm 960
suction connection piece Ø mm 50
suction connection piece Ø mm 100
suctionvolumeowat20m/s Ø100= 560m³/h
suctionatsuctionconnectionpiece Ø100= 170Pa
     Ø50= 918Pa
ambientconditions   5°C
      +35°C
nett weight kg 215
nett weight with scorer kg 224
Drive
Electric motor 230V 400V 400V
50 Hz 50 Hz 50 Hz
inputpowerP1 kW 3,0 3,8 4,8
outputpowerP2 kW 2,2 2,9 4,0
motorrotaryspeed1/min. 2800 2800 2800
drivetype  S6/40% S6/40% S6/40%
ratedcurrent  11,6A 6,1A 8,2A
Scorer
inputpowerP1 kW 0,8
outputpowerP2 kW 0,5
Noise characteristic values
Measurement conditions in accordance with draft pr EN 1870-
1: 1995-07; DIN EN ISO 11202; DIN EN ISO 3746
The values stated are emission values and are there- fore
notnecessarilysafeoperatingvalues.Althoughthereisa
correlationbetweenemissionandimmissionlevels,you
cannot reliably deduce from this whether additional safety
measuresarerequiredornot.Factorswhichcaninuence
the immission level currently at the workstation comprise
thedurationoftheeffects,thecharacteristicsofthework
room,othersourcesofnoiseetc.,forexample,the
number of machines and adjacent operations. The
permissible values per workstation can also vary from
country to country. This information should nevertheless
enable the user to make a better esti- mation of dangers
and risks.
Sound intensity level in dB
ldling L
WA
= 97,5dB(A),
Working L
WA
= 100,4dB(A)
Work place based emission values in dB
ldling L
pAeq
= 86,7dB(A),
Working L
pAeq
= 87,1dB(A)
AmeasurementerrorfactorofK=4dBappliestothe
stated emission values.
lnformation on dust emission
The dust emission values measured in accordance with
the„principlesfortestingdustemission“ofthe
committeeofexpertsofwoodarebelow2mg/m3.This
meansthattheTRKlimitforwooddustwhichisvalidin
theFederalRepublicofGermanywillbepermanently
kept to if the machine is connected to a properly working
dustextractorwithatleast20mlsairspeed.
