18 english
• Forusingthemachinenotasintended,themanufacturer
will not take any liabilities
• Themachineisdesignatedforcommerciallyuse
Rernaining hazards
The rnachine has been built using modern techno- logy in
accordance with recognized safety rules. Some rernaining
hazards,however,maystillexisi.
• Therotatingsawbladecancauseinjuriestongersand
hands if the work piece is incorrectly fed.
• Thrownworkpiecescanleadtoinjuryiftheworkpiece
isnotproperlysecuredorfed,suchasworkingwithouta
limit stop.
• Noisecanbeahealthhazard.Theperrnittednoiselevel
is exceeded when working. Be Sure to wear personal
protective gear such as ear protection.
• Defective saw blades can cause injuries. Regularly
inspect the structural integrity of saw blades.
• Theuseofincorrectordamagedmainscablescanlead
to injuries caused by electricity.
• Evenwhenallsafetymeasuresaretaken,someremaining
hazards which are not yet evident may still be present
• Remaininghazardscanberninimizedbyfollowingthe
instructions in ,,Safety Precautions“, ,,Proper Use“ and in
the entire operating manual.
Scope of delivery
Circularsawbenchts4020partlyassembled
Sawblade Ø 315
Long fence
Crosscut/mitregauge
Rivingknife
Dustextractorhood
Dustextractoraccessories
Suction connection piece
Pushstick
Pushgrip
Assemblytoo
Holding mandre
Assemblyaccessories(accessorypack)
Operating instructions
scorersawbladeØ120(only54630904/0905/0906
Accessories
Model No.
Slidingtablecarriage1400  54630701
Slidingtablecarriage2000  54630702
Slidingtablecarriage1400  54630703
Slidingtablecarriage2000  54630704
Hinglearm   54630705
Fencerail1350extendible  53208180
Wheelbase   53000705
Tablewidthextensionfoldable 54630706
Tablelengthextension  73240170
SUVAsuctionattachment  54601100
Table insert and collar nut for
adjustablegroovingcutter  54630707
Adjustablegroovingcutter  72310709
(onlyallowedtouseincorrespondecewith
SUVAsuctionattachment)  
clampingfencecpl.rightside 79390301
fencerail1500   53000077
automatic switch-on
mechanismALV2   79104010
automatic switch-on
mechanismALV10  79104020
Acessory sawblades
Only install Original scheppach sawblades!
Model Nr.
Special sawblade 6310 4101
Hardened metal sawblade for coated furniture boards
Dimensions:
Total Ø mm 250
Bore Ø mm 30
No.ofteeth 80Z
sawblade 5100 5556
Universaltrimmingbladehardenedmetalteethforlong
and cross cuts in wood and chip board.
Dimensions:
Total Ø mm 315
Bore Ø mm 30
No.ofteeth 48WZ
sawblade 5100 5504
Universaltrimmingbladehardenedrnetaltippedforlong
and cross cuts in solid wood.
Dimensions:
Total Ø mm 300
Bore Ø mm 30
No.ofteeth 48WZ
sawblade 5100 5507
UniversalTCTsawbladeforlengthandcrosscutsinsolid
wood.
Dimensions:
Total Ø mm 300
Bore Ø mm 30
No.ofteeth 72Z
