Schiller AT-2plus - Page 121

16
Schiller AG
Altgasse 68
CH-6340 Baar
Drawn by: Gau
Entw: TM 20
2483CA
07.02.00Size:
S.
Date: Sheet ofA3
ECG CHANNEL C5 + C6 MK14-10 (AT-2plus)
C5
S2
C5-F
C5OS
+5VAi
CAVEiCAVEi
AGNDi AGNDi AGNDi AGNDi AGNDi
AGNDi
AGNDi
-5VAi
R186
30K
R194
15K
C115
150N/1206
R196
7M5
R198
7M5
R201
2K
R234
160R
C119
3N9
R298
47K
R300
1K1
C116
150N/1206
RV14
82V
R301
1K1
R306
3K9/0.1%
R312
39K/0.1%
Q15
SST204
TP41
R319
10K
R343
10K
C121
390P
C123
680P/COG
R346
1G
-5VAIF
C6
S2
K
C6-F
C6OS
CAVEiCAVEi
AGNDi AGNDi AGNDi AGNDi AGNDi
AGNDi
AGNDi
R192
30K
R195
15K
C117
150N/1206
R199
7M5
R200
7M5
R202
2K
R288
160R
C120
3N9
R299
47K
R302
1K1
C118
150N/1206
RV15
82V
R303
1K1
R311
3K9/0.1%
R318
39K/0.1%
Q16
SST204
TP40
R344
10K
R345
10K
C122
390P
C124
680P/COG
R347
1G
-5VAIF
C101
220N/63V
C102
220N/63V
3
2
1
84
U54A
LPC662
5
6
7
U54B
LPC662
3
2
1
84
U55A
LPC662
5
6
7
U55B
LPC662
+5VAi
-5VAi
