Schiller AT-2plus - Page 122

17
Schiller AG
Altgasse 68
CH-6340 Baar
Drawn by: Gau
Entw: TM 20
2483CA
07.02.00Size:
S.
Date: Sheet ofA3
ECG CHANNEL LA + RA MK14-10 (AT-2plus)
LA
S2
LA-F
LAOS
+5VAi
CAVEiCAVEi
AGNDi AGNDi AGNDi AGNDi AGNDi
AGNDi
AGNDi
-5VAi
R348
30K
R350
15K
C125
150N/1206
R352
7M5
R353
7M5
R356
2K
R358
160R
C134
3N9
R362
47K
R364
1K1
C126
150N/1206
RV18
82V
R365
1K1
R368
3K9/0.1%
R370
39K/0.1%
Q17
SST204
TP43
R372
10K
R373
10K
C138
390P
C142
680P/COG
R376
1G
-5VAIF
RA
S2
K
RA-F
RAOS
CAVEiCAVEi
AGNDi AGNDi AGNDi AGNDi AGNDi
AGNDi
AGNDi
R349
30K
R351
15K
C127
150N/1206
R354
7M5
R355
7M5
R357
2K
R359
160R
C135
3N9
R363
47K
R366
1K1
C133
150N/1206
RV19
82V
R367
1K1
R369
3K9/0.1%
R371
39K/0.1%
Q18
SST204
TP42
R374
10K
R375
10K
C139
390P
C144
680P/COG
R377
1G
-5VAIF
C103
220N/63V
C104
220N/63V
3
2
1
84
U56A
LPC662
5
6
7
U56B
LPC662
3
2
1
84
U57A
LPC662
5
6
7
U57B
LPC662
+5VAi
-5VAi
RA1
