Page 1.15
Chapter 1
Operating Elements
SCHILLER AT-2plus 6-Channel ECG Unit
SERVICE HANDBOOK Issue 1 June 1998
Settings (cont.)
Language
The language is selected as follows:
Confirm the selection by pressing
STOP
Notes: The difference between English and American is the mains filter setting - English =
50Hz; American = 60Hz and the physical units.
Note: The language setting for the AT-2plus Memory depends on the software version which
has been loaded (see page 1.27)
User Identification
The user identification is printed on all recordings. The user ID can be the department, doctor or
hospital etc. Enter the user ID as follows:
Press the ALT key followed by key 9, 3, 3
ALT - 9 - 3 - 3
The user entry field is displayed on the LCD. Enter up to 30 characters via the keyboard.
Confirm the new user ID by pressing the ENTER key.
