Schlage CONNECT - Install the Inside Backplate; Backplate Mounting Instructions

4
step
Install the inside backplate.
Route the cable below the bolt and through the hole on the
bottom of the backplate. Secure the backplate with screws.
Hold the touchscreen
on the outside of
the door while you
tighten the screws.
TOP
Make sure
that “TOP”
is facing
out.
Actual Size (2)
Don’t use a power drill!
You may damage your lock!
Phillips screwdriver
1
2
3
4 5
