Cylinder Service Equipment and Tools
Key Gauge
40-104 Full size keys
40-128 A2 System SFIC keys
Blue Punch Key Machine
40-075 Classic Obverse and Everest C Family keys only
(Conventional and Primus)
40-071 Everest B Family small format IC keys only
40-074 Upgrade jaw kit adds Everest C Family capability to
Blue Punch machines made before July 1999
Pin Kits
40-119 For full size conventional cylinders
Contains bottom, top and master pins, springs,
cap pins, cap pin springs, caps, follower,
tweezers, key gauge, shims, cap removal tool
40-070 Primus
Contains finger pins, sidebars, springs, plug holder
40-129 SFIC wooden pin kit for A2 System
Contains all pins and springs, key gauge, tweezers,
capping tool, capping block, ejector tool
Small Format IC Tools (included in 40-129 kit)
40-137 Capping block
40-136 Ejector tool
40-138 Capping tool
Full Size Cylinder Tools (included in kits above)
40-066 Primus plug holder
40-116 Shell loading tool
M204-200 Pin tweezers
M540-056 Cylinder cap removal tool
