Door Preparation
Specifications
Handing:
Not handed, except Flair design.
Door Thickness:
1⅜" to 2"
(35 mm-51 mm)
except S40D: 1³⁄₈ to 1⁷⁄₈ (35 mm-48 mm)
Backset:
Universal backset latches standard, fit either 2⅜"
(60 mm) or 2¾" (70 mm). 5" (127 mm) optional.
Fronts:
Steel. 1⅛˝ x 2¼˝
(29 mm x 57 mm)
square corner,
beveled, for 2¾˝ backset standard. For availability with
specific backsets, see page 6.
Lock Chassis:
Tubular construction. Zinc with steel cover.
Latch Bolt:
Brass, chrome plated, ½˝ (
13 mm) throw, deadlocking.
Exposed Trim:
Levers are zinc base, plated to match finish symbols.
Roses, latch faceplates and strikes are wrought brass or
bronze.
Strike:
T-strike 1
¹⁄₈˝ x 2³⁄₄˝ (29 mm x 70 mm) x 1¹⁄₈˝ (29 mm)
lip to center with box standard. Optional strikes, lip
lengths and ANSI strike box available. See page 7.
Cylinder & Keys:
Commercial: 6-pin patented Everest C123 keyway stan-
dard with two nickel silver keys per lock.
Residential: 6-pin C keyway, keyed 5-pin.
Keying Options:
Interchangeable core and Primus
®
high security
cylinders. Master keying, grand master keying,
and construction keying.
Warranty:
Commercial: three-year limited.
Residential: Full mechanical lifetime.
Certifications
ANSI
Meets or exceeds A156.2 Series 4000, Grade 2
strength and operational requirements.
Federal
Meets FF-H-106C.
California State Reference Code
(Formerly Title 19, California State Fire Marshal Standard)
Neptune and Saturn designs comply; levers return to
within ½˝ of door face.
UL / cUL:
All locks listed for A label single doors, 4´ x 8´.
Letter F and UL symbol on latch front indicate listing.
UL437 Listed locking cylinder optional: specify
Primus 20-500 Series cylinder.
