Parts and kits
Schlage • ND-Series service manual • 95
Parts and kits
Conversion kits
Prior versions of ND locks may be upgraded to new parts and assemblies with conversion kits consisting of a spring cage
assembly and lever assembly. Kits may be ordered for one or both sides of the lock. Kits are available for all lever designs.
For allowable finishes, refer to current Schlage Commercial Price Book.
04-400, Outside conversion kit
Outside lever type Cylinder type Spring cage
assembly
Lever Stop catch Driver
Closed (ND10) –
N523-218 03-230 – –
Closed (ND12, ND30, ND45, ND60) –
N523-218 03-230 N523-041 –
Open KIL Schlage KIL
N523-218 03-231 – –
FSIC Schlage FSIC
N523-218 03-232 – –
SFIC Schlage SFIC
N523-218 03-200 – –
SARG KIL Sargent KIL
N523-218 03-244 – 09-060
SARG FSIC Sargent FSIC
N523-218 03-277 – 09-063
COR RUSS 6P FSIC Corbin Russwin 6-pin FSIC
N523-218 03-266 – 09-062
YALE 6P FSIC Yale 6-pin FSIC
N523-224 03-255 – 09-061
04-600, Inside conversion kit
Inside lever type Cylinder type Spring cage
assembly
Lever Button Driver
Closed –
N523-221 03-230 – –
Closed, electrified –
N523-221 03-230 – –
Open, push button –
N523-221 03-233 N523-209 –
Open, push and turn button –
N523-221 03-233 N523-210 –
Open, spanner button (ND85) –
N523-221 03-233 N523-211 –
Open KIL Schlage KIL
N523-222 03-231 – –
FSIC Schlage FSIC
N523-222 03-232 – –
SFIC Schlage SFIC
N523-222 03-200 – –
SARG KIL Sargent KIL
N523-222 03-244 – 09-060
SARG FSIC Sargent FSIC
N523-222 03-277 – 09-063
COR RUSS 6P FSIC Corbin Russwin 6-pin FSIC
N523-222 03-266 – 09-062
YALE 6P FSIC Yale 6-pin FSIC
N523-255 03-255 – 09-061
