7 Technical Specifications
7.1 Interfaces
7.1.1 DSL Line Interface
Standard referred: ETSI TS 101 524, ITU-T G.991.2 Annex B (Revision 2004)
Number of Pairs: 1, 2, 3 or 4
Line Rate per Pair: 192 – 5'696 kbit/s
Line Code: Trellis-coded PAM-16, PAM-32
Nominal Line Impedance:
135Ω
Transmit Power @ 135Ω:
According to TS 101 524
Overvoltage Protection: ITU-T K.21 (07/03) K.44(7/03)
Connector Type: RJ-45, 8 pin
7.1.2 Ethernet Interfaces
Standard referred: IEEE 802.3
Crossover Auto-Crossover
Bitrate 10/100 Mbps (Auto-negotiation)
Duplex Mode Half/Full Duplex (Auto-negotiation)
7.2 Power Consumption
Model Power Consumption
SZ.441.V400 < 10 Watts
SZ.441.V800 < 10 Watts
Revision: 2007-05-24
7-1
