7.3 Ethernet
Maximum Frame Size 1'522 bytes
Number of VLANs 14 with Switch in 802.1Q mode
Traffic Shaping Configurable
Number of Queues 4
CoS Classifiers Layer 2 Priority, Layer 3 DSCP, IP-based filter
7.4 Management Functions
Management Protocols SNMPv1 (RFC 1155-1157), SNMPv2c (RFC 2578-2580, 3416-3418),
SNMPv3 (RFC 3411-3418, 3584), Telnet (RFC 854)
Supported MIBs MIB-II, RFCs 1213, 2011, 2012, 2013
Firmware Upgrade TFTP (RFC 1350)
7.5 Environment
7.5.1 Climatic Conditions
Storage: ETS 300 019-1-1 Class 1.2
-25°C … +55°C, 10% .. 100% RH
Transportation: ETS 300 019-1-2 Class 2.3
-40°C … +70°C, max. 95% RH
Operation: ETS 300 019-1-3 Class 3.2
-5°C … +45°C, 5% .. 95% RH
7.5.2 Safety
According to EN 60950-1:2006 (IEC 60950-1:2005)
7.5.3 EMC
According to EN 300 386 V1.3.3
7.6 Physical dimensions and weight
Height 43mm
Width 220mm
Depth 195mm
Weight 800g
