FITTING INSTRUCTION STICKERS:
The kit includes three (3) operation and alignment stickers to assist the operator in normal
operation. It is important that all the calibration and weighing be carried out in a repeatable
fashion. The stickers assist the operator to weigh in the same position each lift.
Lift trucks
• Operator instruction sticker: Mount this on the dash of the Lift truck
• Arrow Sticker →: This acts as a pointer for the operator and is located on the back of
the fork Carriage or moving mast slide.
• Position Sticker ( marked 1 - 2 ) : This sticker is affixed to the Stationary Mast in a
position such that when the forks of the lift truck are in the desired weighing position,
the two (2) on the sticker is aligned with the Arrow
→ previously fixed to the fork
carriage or moving mast slide. Generally, the forks are positioned around 300 mm to
400 mm off the ground for pallet weighing work.
TECHNICAL NOTE:
CAUTION - WELDING!
TO AVOID DAMAGE TO THE SENSITIVE ELECTRONIC COMPONENTS IN THE SYSTEM,
THE POWER SUPPLY CONNECTOR SHOULD BE UNPLUGGED FROM THE FWS 114
UNIT WHILST ANY ELECTRIC WELDING IS BEING CARRIED OUT!
