Assembly
08.00 | MPG-plus | Assembly and operating manual | en | 0389216
21
Item Mounting MPG-plus
16 20 25 32 40 50 64
Side A
1 Screw M2 M2.5 M3 M4 M4 M5 M5
Maximal screw-in
depth [mm]
4 5.5 7.4 8.9 8.9 10.9 10.9
2 Centering sleeve Ø3 Ø4 Ø5 Ø6 Ø6 Ø8 Ø8
Side B
4 Screw M2 M2.5 M3 M4 M4 M5 M5
Maximal screw-in
depth [mm]
4 6 6.9 8.9 8.9 10.4 10.4
3 Centering sleeve Ø3 Ø4 Ø5 Ø6 Ø6 Ø8 Ø8
Side C
5 Screw M1.6 M2 M2.5 M3 M3 M4 M4
Screw according
to norm
DIN EN ISO 4762
Max. strength class 8.8
3 Centering sleeve Ø3 Ø4 Ø5 Ø6 Ø6 Ø8 Ø8
Connections at the
base jaws
Designation MPG-plus
16 20 25 32 40 50 64
Thread in base jaws M3 M4 M4 M5 M5 M6 M8
Maximal screw-in depth
from stop surface [mm]
3 3.5 4 5 6 8 10
Maximal tightening
torque of mounting
screws [Nm]
1.2 3.1 3.1 6.1 6.1 10 25
Diameter cylindrical pins
[mm]
1.5 1.5 1.5 2 2.5 3 4
