Montage- und Betriebsanleitung für 3-Backen-Parallelgreifer
PZN-plus mit Werkzeugschnittstelle HSK/KM/Capto
Operating manual for 3-Finger Parallel Gripper
PZN-plus with tool interface HSK/KM/Capto
Adapterplatte / Adapter plate
Drossel / throttle
Adaterstück für Drossel /
Adapter piece for throttle
Abspritzschlauch / Hose
Bild 1 / Illustration 1
Manometer / Pressure gauge
Bild 2 / Illustration 2
Einstellsatz / Adjustment set
Anschluss des Einstellsatzes
Connection of the adjustment set
Bild 3 / Illustration 3
