Assembly
18
03.00 | PWG-S | Assembly and operating manual | en | 389361
The inductive proximity switches are electronic components,
which can react sensitively to high-frequency interference or
electromagnetic fields.
Check to make sure that the cable is fastened and installed
correctly. Provide for sufficient clearance to sources of high-
frequency interference and their supply cables.
Parallel switching of several sensor outputs of the same type
(npn, pnp) is permissible, but does not increase the permissible
load current.
Note that the leakage current of the individual sensors (approx.
2 mA) is cumulative.
If you require further information on sensor operation, contact
your SCHUNK contact person or download information from our
homepage.
Technical data for the sensors can be found in the data sheets
(included in the scope of delivery).
