4. Description
Two Drip Trays (attached to the
bottom of the motors)
Filters
Lamp (For GU10 ttings, please twist to remove)
Male Plug (Main Power 240V)
Two 150mm Outlet
Speed Control
This rangehood is equipped with a 3 speed mechanical control.
Speed control usage suggestions:
• Low speed for simmering.
• Medium speed for light cooking.
• High speed for heavy frying or heavy cooking.
Main Rangehood
Mounting Bracket
1
1
Extension Flue
2
2
Main Flue
3
3
4
4
5
5
6
6
7
8
7
8
NOTE: Filter and light quantity may vary from model
to model.
