6.3 TRANSMITTER
Power supply
from exchangeable battery cassette (7.2 V; NiMH) or vehicle battery
when link cable is connected
Weight
1.7 / 1.95 kg (without / with battery)
Degree of protection
IP 65, protected against the ingress of dust and water-jets under
standardized conditions
Duration of use for opera-
tion from battery
8 hours max.
Operating temperature
range
approx. -25 °C to 70 °C (-13 °F to 158 °F)
Dimensions
290 x 160 x 190 mm
Radio transmission range
approx. 100 m in industrial environment
Length of link cable
standard length: 10 m
6.4 BATTERY CHARGER
Place of installation
depending on machine type, either inside the driver's cab or beside
the VECTOR control cabinet
Power supply
from vehicle battery
Weight
0.25 kg
Degree of protection
IP 21, protected against dripping water and the ingress of bodies with
more than 12.5 mm diameter under standardized conditions
Power consumption
10 – 20 mA without battery in charger, 320 – 560 mA during battery
charge
Weight
0.25 kg
Operating temperature
range
approx. -25 °C to 70 °C (-13 °F to 158 °F)
Observe battery charge temperature limits.
See chapter 15.
Dimensions
252 x 85 x 36 mm
Fuse protection
depending on machine type
inside in the driver's cab via the fuse of the truck's socket outlet (ciga-
rette lighter) or
inside the control cabinet via the 7.5 A fuse of the VECTOR control
power supply
