Attach the Secondary Chain
Parts: secondary chain, frame assembly
Hardware: master link, chain link plate, chain pin
Tools: Needle Nose Pliers, 17 mm open and box
end wrench.
1. Wrap the secondary chain around the inner sprocket
on the rear hub and drive sprocket on the rear axle.
2. Adjust the position of the rear frame until the ends of
the secondary chain meet each other, leaving one
chain link length space in between the ends.
3. To connect the two ends of the chain:
a. Insert the pegs of the master link through both
ends of each chain link.
b. Place the chain link plate over the pegs of the
master link.
c. Snap the chain pin onto a peg of the master
  linksoitisatagainsttheouterlinkplate.
d. With the needle nose pliers, carefully slide the
clip onto the link pins until it is locked.
4. Pull the rear frame back so the secondary chain is
taut and there is less than 5 mm of play up or down.
Important! Check the rear frame is square
(perpendicular) to main frame. Failure to square
the frames will affect performance of the tricycle.
5. Ensurethesquareboltisintheslot.Firmlytighten
the four bolts holding the rear frame to the
main frame.
inner sprocket
drive sprocket
1
a
b
5
2
Have a second
person pulling the
chain taut while
tightening the bolts.
Tip!
3
4
c
