WARNING!
13
Attach the Rear Wheels
Failure to properly tighten the nuts holding the wheels
onto the tricycle may result in poor riding performance,
the tire falling off and serious injury or death. Always
be sure the wheels are securely attached to the frame
before using the tricycle.
Parts: Drive wheel, non-drive wheel
Hardware: 2 plastic caps, 2 locknuts, 2 washers.
The locknuts come attached to the axle.
Remove the locknuts before you begin this
procedure.
Tools: 17 mm open and box end wrench
See the facing page for diagrams of the following steps.
1. Place the drive wheel (with a notched opening) on
the axle.
2. Place the washer on the axle.
3. Place the locknut on the axle and tighten securely.
Note: The drive
wheel hub has
a notched
opening that
matches the
notched axle.
4. Screw the plastic caps on each end of the axles.
5. To attach the non-drive wheel repeat steps one
through four.
Note: To prevent the axle from turning while
attaching the non-drive wheel, it is important to hold
the drive wheel while tightening the locknut on the
non-drive wheel.
