Schwinn 26” - Attach the Saddle

31
Attach the Saddle
!
WARNING!
Insufcientlockingpressureontheseatstemmay
result in the seat slipping, loss of control and serious
injury or death. Be sure the seat is locked and capable of
supporting the weight of the rider before
using the tricycle.
Parts: Saddle, Saddle stem
Tools: 14 mm open and box end wrench, Adjustable Pliers
1. Place the saddle on the saddle stem.
2. Tighten the nuts on each side of the saddle stem until
the saddle is securely attached to the stem.
3. Release the quick release clamp.
4. Place the seat stem into the frame seat tube until the
Minimum Insertion mark is not visible.
5. Turntheadjustingnutuntilthereissufcient
pressure to hold the seat in place when the quick
release lever is closed.
6. Close the quick release clamp.
2
1
2
4
5
Minimum
insertion mark
6
