26
cable adjustment barrel
2
brake cable seated in the
adjusting barrel bolt
adjusting
barrel bolt
pad control
lever
3
rear brake lever
rear brake
shell
brake cable
inner wire
5
brake band on drum
1
pinch bolt
adjustment
barrel lock nut
4
7
6
