Schwinn 430 - Parts List

3
HARDWARE
Note: Please verify you have all correct parts and quantities before
assembling unit.
If you are missing items, are short quantities, or have damaged
components, please contact Schwinn at 1.800.864.1270
M8 x 15L
BUTTON HEAD (32)
M8 x 20L
BUTTON HEAD (4)
M8 x 20L HEX HEAD
THREAD LOCK (4)
M8 WASHER
WIDE (4)
M5 x 20L
PHILLIPS HEAD (2)
M5 x 10L
PHILLIPS HEAD (4)
M8 WASHER
REGULAR (36)
M8 WASHER
LOCKING (40)
M8 x 25L FLAT HEAD
THREAD LOCK (6)
ALLEN WRENCH (1)
COTTER PIN (2)
END CAPS (4)
COMBO WRENCH (2)
STAPLED TO THE HARDWARE CARD
