Schwinn 430 - Equipment Assembly Instructions; Step 1: Attach Front Stabilizer to Frame

5
PARTS LIST
PARTS LIST
Ref. Description Qty
A MAIN FRAME ASSEMBLY 1
B LEFT FOOT ASSEMBLY 1
C RIGHT FOOT ASSEMBLY 1
D CONSOLE HANDLEBAR 1
E FRONT STABILIZER 1
F WATER BOTTLE HOLDER 1
G REAR STABILIZER 1
H EXTRUSION ASSEMBLY 2
I EXTRUSION HANDLEBAR ASSEMBLY 1
K CONSOLE MAST 1
L ARM PIVOT ROD 1
M LOWER LEFT HANDLEBAR 1
O LEFT UPPER HANDLEBAR 1
P RIGHT UPPER HANDLEBAR 1
Q RIGHT LOWER HANDLEBAR 1
R LEFT LEG 1
S RIGHT LEG 1
T FOOT MOUNT PLATE 2
U CONSOLE 1
V ASSEMBLY/OWNER MANUALS 1
W AC ADAPTOR 1
