SpECIfICATIONS

Before Assembly

Select the area where you are going to set up and operate your machine. For safe operation, the location must be on a

hard,levelsurface.Allowaworkoutareaofaminimum187.2cm(73.7”)x248.2cm(97.7”).

Basic Assembly Tips

Follow these basic points when you assemble your machine:

• Readandunderstandthe“ImportantSafetyInstructions”beforeassembly.

• Collect all the pieces necessary for each assembly step.

• Usingtherecommendedwrenches,turntheboltsandnutstotheright(clockwise)totighten,andtheleft(counterclock-

wise)toloosen,unlessinstructedotherwise.

• When attaching 2 pieces, lightly lift and look through the bolt holes to help insert the bolt through the holes.

• Theassemblyrequires2people.

Machine Weight:  52.2kg(115lbs.)

Power Requirements: 2AABatteries(LR6)

 OperatingVoltage:  1.0-3.3VDC

Maximum User Weight: 136kg(300lbs.)

Regulatory Approvals:

ThisproductconformstotheapplicableENISO20957InternationalStandardsforStationaryTrainingEquipment,ClassS

DONOTdisposeofthisproductasrefuse.Thisproductistoberecycled.Forproperdisposalofthisproduct,

please follow the prescribed methods at an approved waste center.

129.2 cm

( 50.9” )

65.2 cm

( 25.7” )

126.3 cm

( 49.7” )

Schwinn AD6 Assembly Manual

Other manuals for Schwinn AD6
