Schwinn AD6 Assembly Manual

6
Adecalhasbeenappliedtoallright(“R”)andleft(“L”)partstoassistwithassembly.
Item Qty Description Item Qty Description
1 1 Frame 9 1 Pedal Strap, Left
2 1 Console Support Bar 10 1 Pedal, Left
3 1 Console 11 1 Foot Peg, Left
4 1 Water Bottle Holder 12 1 Stabilizer, Front
5 1 Handlebar, Left 13 1 Foot Peg, Right
6 1 Seat 14 1 Pedal, Right
7 1 Seat Post 15 1 Pedal Strap, Right
8 1 Stabilizer, Rear 16 1 Handlebar, Right
pARTS
5
7
8
4 6
3
2
16
1
13
14
10
12
11
17
R
15
9
STOP
