A Adjustment Handle, Seat Slider N Flywheel
B Seat Slider O Power Inlet
C Seat P Front Stabilizer
D Adjustment Handle, Seat Post Q Transport Wheel
E Emergency Brake/Resistance Adjustment Knob R Leveler
F Console S Rear Stabilizer
G Media Tray T Pedal w/Foot Restraint and Shoe Cleat
H Handlebar Assembly U Cover, Drive Belt
I Adjustment Handle, Handlebar Slider V Shoe Clips (Cleats)
J Water Bottle Holder W USB Charging Port
K Dumbbell Rack (Dumbbells only supplied with the
IC4 machine)
X Bluetooth
®
Connectivity (not shown)
L Adjustment Handle, Handlebar Post Y Bluetooth
®
Heart Rate (HR) Receiver (not shown)
M Brake Assembly
FEATURES
WARNING! Use the values calculated or measured by the machine’s computer for reference purposes only. The
heart rate displayed is an approximation and should be used for reference only. Over exercising may result in
serious injury or death. If you feel faint stop exercising immediately.
D
A
B
F
C
E
G
H
I
J
K
L
M
N
O
Q
R
R
P
S
T
V
U
W
