Schwinn IC4 - Assembly Instructions; Attach Stabilizers to Frame

8
Tools
Included
Item Qty Description
A 2 Adjustment Handle, Handlebar / Seat
B 2 Flat Washer, M10 Wide
C 1 Adjustment Handle, Handlebar Post
HARDWARE / TOOLS
#2
13 mm
14 mm
15 mm
1. Attach Stabilizers to Frame
Note: The hardware (*) is pre-installed and not in the Hardware Bag. If a tube is pre-installed in the stabilizer bracket,
remove and set it safely aside.
3 mm
6 mm
*
*
*
6mm
X4
1
6
8
ASSEMBLY
A B C
