Technical Procedure
3. Use a #2 phillips screwdriver to remove the
pan head screw securing the sensor to the
brake assembly.
Fig. 33
4. Remove the sensor from the brake assembly.
5. Follow steps 1-4 in reverse to install the new
sensor.
Fig. 34
