Schwinn Z - Page 28

Page 28
637-8808 Rev. J
Technical Procedure
7. Use a 3mm allen key to remove the five (5)
button head cap screws from the left side
outer fork guard, then remove the fork guard.
8. Carefully disconnect the LED board cable
from the LED board.
Fig. 55
9. Use a 19mm open-ended wrench to loosen
the flywheel axle nut.
Fig. 56
