15.2 Test Fixtures
Description
Manufacturer
Mfg Part No.
Small Diode Socket (lead dia. < 0.040)
Textool
202-0081-00-0602
Large Diode Socket (lead dia. < 0.050)
Textool
204-3017-00-0602
DO-4/5 Stud Diode Socket
Loranger
2446-022-6215
TO-3/66 Socket
CTI
499-026-23
TO-5/18 Socket
Textool
204-4047-00-0602
TO-92 Socket
Textool
203-0095-00-0602
TO-220/218 Socket
Textool
203-2737-55-0602
SOT-23 Socket
Loranger
3334-061-6215
TO-59/65/63/48 Socket
Textool
203-0200-00-0602
6-pin TO-5 Opto Socket
Textool
206-0224-50-0602
8-pin TO-5 Opto Socket
Textool
208-0116-50-0602
14-pin DIP Zero Insertion Force Socket
Textool
214-3339-00-0602
Small Test Fixture Enclosure
(1.96 x 2.55 x 1.37 polycarbonate)
Rose Enclosures
03050704
Large Test Fixture Enclosure
(3.14 x 3.22 x 2.16 polycarbonate)
Rose Enclosures
03080806
Banana Jacks
E.F. Johnson, Concord
108-2303-621, 01-2310-1-02
Suppression Coil
Scientific Test
FX-COIL
Ferrite Beads
Allen Bradley
F1832-1-06
Manufacturer’s Addresses:
Textool
1001 Fountain Parkway
Grand Prairie, TX 75050
214 647 0392
Loranger
817 Fourth Ave.
Warren, PA 16365
814 723 2250
Component Technologies
(CTI)
14425 N. Scottsdale #300
Scottsdale, AZ 85260
603 998 1484
Rose Enclosures
12140 Parklawn Dr.
Rockville, MD 20852
301 984 3770
E.F. Johnson
P.O. Box 59089
Minneapolis, MN 55459
507 835 6222
Table 15-2 Test Fixtures
15.3 Self-Test Fixture
600-001
Reference Designation
Description
Qty
R1, R2
100 Ω, 1W
2
R3
10 MΩ, 1%
1
R4
3.3 Ω, ¼W
1
R5
18 MΩ, ½W
1
R6
1.5 MΩ, ¼W
1
Banana Plug (PCB)
Concord 01-2255-6-01
16
Spacer
¼” 1680-632-SS
6
Screws
6-32 x 5/16” SS (Pexi-glass side)
6
Screws
6-32 x ¼ (PCB side)
6
Plex-Glass
1
PCB
1
Table 15-3 Self-Test Fixture (600-001)
