6 – PC SOFTWARE
MODEL 5000 SERIES MANUAL Version 1.23 6-19
6.4.9 Retest
The “Retest” option is required. When selected the datalog data for the tested device
is displayed in the Exact Value window. A Selection Box is opened. If the operator
selects “ok”, the data for that device is not sent to the datalog file and the serial
number of the device is sent to the STI 5000 Series Tester. The next start will use
the serial number of the device selected for retest. Note: this should only be used
when manually testing devices.
6.4.10 Excel Spreadsheet
The “Excel Spreadsheet” option is required and Microsoft Excel must be installed on
the PC. When selected, opens Microsoft Excel application, if required, and adds an
Excel workbook. If Multiplex operation, there can be an Excel workbook for each
Multiplex station. All datalog data is then sent directly to the Excel workbook sheet 1.
Column headings are added as required. Single test measure data is sent directly to
the Excel workbook and is placed in sheet 2 of the workbook.
6.4.11 Print Selected Text
Using the mouse, highlight the area of the Exact Value window desired and then
select this option to send the highlighted text to the printer.
6.4.12 Copy to Clipboard
Copies the highlighted text to the Windows clipboard.
6.4.13 Clear Window
Clears the Exact Value window (does not affect any data saved to disk).
6.4.14 Clear Error
Clears any errors displayed at the bottom of the window.
6.4.15 Auto Verify
Requires the STI AC-600 Auto Verification Option.
6.5 Lot Summary Popup Menu
6.5.1 Lot Summary
When checked, indicates the STI 5000 Series Tester will send complete summary
data at the end of each sequence.
6.5.2 Start
Issues a start test sequence command to the STI 5000 Series Tester.
6.5.3 Zero Counts
Sends the zero count command to STI 5000 Series Tester. All sort counts, fail
counts, and totals are reset.
