2| 1.0 Product Introduction
1.2.2 Product walkthrough
1. Single IVM motorised body
2. Probe holding rod
3. Dovetail rod/probe holding assembly (PH-1000)
4. Aluminium fastening strip
5. Stereotaxic frame
6. Z axis motorised body
7. Y axis motorised body
8. X axis motorised body
9. Stoelting bracket (IVM-545-00)
10. IVM Column Assembly - Attaches Y to X (IVM-525-00)
11. IVM Angle Block Assembly - Attaches X to Z (IVM-535-00)
11
