4| 2.0 Packing List
2.0 Packing List
If the outside of the shipping packaging is damaged, notify your shipping
department immediately. The shipping department may wish to notify
the carrier at this point.
If the shipping carton is not damaged, carefully remove and identify all of
the components as listed below. If any of items are missing, contact
Scientifica Ltd. Please retain the packaging for storage or future
transportation of the system.
2.1 Standard items
• Three axes in vivo micromanipulators (IVM) X, Y and Z
• 1U controller rack
• “PatchPad-One” user interface and connecting cable
• 25 Way to 25 Way Parallel Cable
• User interface cable (15-way D-type to RJ45)
• Breakout box
• Mains power cable
• LinLab Configuration software CD
• USB Cable
2.2 Brackets
Standard brackets:
• IVM Column Assembly - Attaches Y to X (IVM-525-00)
• IVM Angle Block Assembly Attaches X to Z (IVM-535-00)
• Dove tail probe holder accessory (PH-1000)
Optional brackets:
• Axon Dovetail Adapter Plate (IVM-560-00)
• Extended probe holder accessory (IVM-530-00)
• IVM Static Base with Circumferential Mounting Slots (IVM-590-
00)
(See Product walkthrough section 1.2.2 for images)
2.3 Control options
• Patchpad
• Control Cube
