OEM Manual – CUBO
2
AQUA
Pag. 28-EN UMT/WG T BT Rev3.0 – 08/10/2021
Mask
index
Topic
Description
Serious
alarm
Normal
alarm
Action
Delay
Reset
ALA02
Gas cooler pressure probe broken
or disconnected.
Gas cooler pressure probe broken,
disconnected or not properly
configured
x
No action on the regulation
The opening of HPV valve
will be fixed at a safety
value settable in mask
Fhb13
No delay
Automatic
ALA03
External temperature probe broken
or disconnected.
External temperature probe could
be broken, disconnected or not
properly configured
x
All Functions managed by
this probe will be disabled:
- Floating Condensing
setpoint
- auto-switch of regulation
on T_ext in case of
T_outlet_GC is fault (mask
Dag14)
- speed up opening of gas
cooler 3-Way valve
according to T_ext (mask
Dag13)
No delay
Automatic
ALA24
Suction pressure probe broken or
disconnected.
Suction pressure probe broken,
disconnected or not properly
configured
x
Shut off of LT/MT
compressor (according to
the setting made on mask
Cag03)
No delay
Automatic
ALA25
Suction temperature probe broken
or disconnected.
Suction temperature probe broken,
disconnected or not properly
configured
x
No action on the regulation
No delay
Automatic
ALA43
gas cooler out temp.probe broken.
Gas Cooler outlet temperature
probe broken, disconnected or not
properly configured
x
Shut off Gas Cooler 3way
valve
No delay
Automatic
ALA55
Parallel line suction pressure probe
broken or disconnected.
Parallel suction pressure probe
broken, disconnected or not
properly configured
x
No action on the regulation
Parallel Compressor will be
shuted off by regulation
No delay
Automatic
ALA 56
Parallel line suction temperature
probe broken or disconnected.
Parallel suction temperature probe
broken, disconnected or not
properly configured
x
No action on the regulation
No delay
Automatic
ALA57
LT line discharge pressure probe
broken or disconnected.
LT discharge pressure probe
broken, disconnected or not
properly configured
x
Shut off LT compressor
No delay
Automatic
ALA58
LT line discharge temp probe
broken or disconnected.
LT discharge temperature probe
broken, disconnected or not
properly configured
x
No action
No delay
Automatic
ALB02
GAS COOLER
PRESSURE
Common high condensing pressure
switch alarm.
High Pressure pressure switch (for
Parallel/MT compressor). It is active
when Gas Cooler pressure is higher
than the pressure switch threshold
x
Shut off Parallel/MT
compressor
Settable
(by mask
Hc01)
Automatic
/ manual
