SCM Cuno 2 Aqua - Cooling Capacity Table

EN
OEM Manual – CUBO
2
AQUA
UMT/WG T BT Rev3.0 – 08/10/2021 Pag. 43-EN
20 Cooling capacity Table
UMT/WG T 030 BTDX
T_water_i
n [°C]
Evaporation Temperature [°C]
-35
-30
-25
-20
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
min
max
max
min
max
max
min
max
max
min
max
max
40
579
2315
1937
1,20
704
2814
2117
1,33
780
3119
2160
1,44
890
3558
2247
1,58
38
579
2315
1857
1,25
704
2814
2051
1,37
780
3119
2090
1,49
890
3558
2168
1,64
32
579
2315
1657
1,40
704
2814
1985
1,42
780
3119
2010
1,55
890
3558
2090
1,70
20
579
2315
1167
1,98
704
2814
1332
2,11
780
3119
1358
2,30
890
3558
1362
2,61
MEPS
2,32 (according to Ecodesign Directive EN 2009/125/EC)
V/Ph/Hz
230/1+N+PE/50
UMT/WG T 045 BTDX
T_water_i
n [°C]
Evaporation Temperature [°C]
-35
-30
-25
-20
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
min
max
max
min
max
max
min
max
max
min
max
max
40
877
3507
2930
1,20
1066
4263
3207
1,33
1208
4830
3290
1,47
1342
5369
3370
1,59
38
877
3507
2810
1,25
1066
4263
3086
1,38
1208
4830
3176
1,52
1342
5369
3259
1,65
32
877
3507
2510
1,40
1066
4263
2987
1,43
1208
4830
3067
1,57
1342
5369
3141
1,71
20
877
3507
1770
1,98
1066
4263
2010
2,12
1208
4830
2090
2,31
1342
5369
2053
2,62
MEPS
2,32 (according to Ecodesign Directive EN 2009/125/EC)
V/Ph/Hz
230/1+N+PE/50
UMT/WG T 067 BTDX
T_water_i
n [°C]
Evaporation Temperature [°C]
-35
-30
-25
-20
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
min
max
max
min
max
max
min
max
max
min
max
max
40
1307
5227
4294
1,22
1554
6216
4800
1,30
1725
6899
4787
1,44
1886
7544
4777
1,58
38
1307
5227
4054
1,29
1554
6216
4448
1,40
1725
6899
4621
1,49
1886
7544
4597
1,64
32
1307
5227
3694
1,41
1554
6216
4298
1,45
1725
6899
4458
1,55
1886
7544
4416
1,71
20
1307
5227
2704
1,93
1554
6216
3010
2,07
1725
6899
2990
2,31
1886
7544
2881
2,62
MEPS
2,26 (according to Ecodesign Directive EN 2009/125/EC)
V/Ph/Hz
400/3+N+PE/50
UMT/WG T 100 BTDX
T_water_i
n [°C]
Evaporation Temperature [°C]
-35
-30
-25
-20
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
Cooling
Capacity [W]
Pe
[W]
COP
min
max
max
min
max
max
min
max
max
min
max
max
40
2019
8075
6634
1,22
2297
9187
7094
1,30
2513
10050
6974
1,44
2705
10818
6847
1,58
38
2019
8075
6263
1,29
2297
9187
6574
1,40
2513
10050
6732
1,49
2705
10818
6597
1,64
32
2019
8075
5707
1,41
2297
9187
6352
1,45
2513
10050
6495
1,55
2705
10818
6326
1,71
20
2019
8075
4177
1,93
2297
9187
4454
2,06
2513
10050
4356
2,31
2705
10818
4129
2,62
MEPS
2,26 (according to Ecodesign Directive EN 2009/125/EC)
V/Ph/Hz
400/3+N+PE/50
Note: Insterstage SST variable from -10°C to 0°C.
