SCM Cuno 2 Aqua - Electrical Details; General Information and Limits

EN
OEM Manual – CUBO
2
AQUA
UMT/WG T BT Rev3.0 – 08/10/2021 Pag. 41-EN
18 General information and limits
General Characteristics
Cubo2 AQUA line
models
UMT/WG T 030 BT DX
UMT/WG T 045 BT DX
UMT/WG T 067 BT DX
UMT/WG T 100 BT DX
Refrigerant
R744 (CO2)
Compressor
Toshiba
1x DY30N1F-10FU - BT
1x DY30N1F-10FU -
Paral.
1x DY45N1F-10FU BT
1x DY45N1F-10FU Paral.
1x DY67L1F-10FU - BT
1x DY67L1F-10FU -
Paral.
1x RY100L1F - BT
1x DY100L1F - Paral.
Motor
Rotary Compressors
Number of cylinders
1
1
2
2
Number of poles
4
Moto type
DC Brushless
Revolution range
25 ≈ 100 rps
25 ≈ 100 rps
25 ≈ 100 rps
25 ≈ 100 rps
Oil charged per Rotary
Compressor
520 ml
520 ml
450 ml
450 ml
Oil type
PAG VG100
Discharge pressure
125 bar max
125 bar max
125 bar max
125 bar max
Suction pressure
12 ≈ 41 bar
12 ≈ 41 bar
12 ≈ 41 bar
12 ≈ 41 bar
Evaporating temp.
-30 °C ≈ -20 °C
Susction Superheating
10 K ≈ 20 K
Discharge temperature
max 130 °C
Ambient temp.
-15 °C ≈ +43 °C
-20 °C only with winter kit option
Water Inlet temp.
+7 °C ≈ +37 °C
System
Receiver
8 lt ( The max permitted CO2 charge must guaranty that, in case of pump down at EEV in front
of Evaporators, refrigerant inside the receiver will not exceed 7.2kg)
Suction line
3/8" K65 (9,52mm)
3/8" K65 (9,52mm)
3/8" K65 (9,52mm)
1/2" K65 (12,7mm)
Liquid line
3/8" K65 (9,52mm)
3/8" K65 (9,52mm)
3/8" K65 (9,52mm)
3/8" K65 (9,52mm)
PS Suction / Liquid
80 bar / 80 bar
PED Category
II
Dimensions (A x B x H)
1545 x 570 x 805 mm
Generic
Transport dimensions (A x
B x H)
1650 x 650 x 950 mm
(Net) Gross weight
(176 Kg) 194 Kg
Transport way
Pallet & Carton
Painted
RAL 7035
Sound level (max speed)
1)
41 dBA
41 dBA
42 dBA
42 dBA
1)
Sound pressure and sound power analytically calculated. Sound pressure level at 10 m in free field.
19 Electrical details
Electrical Information
Cubo2 AQUA line
UMT/WG T 030 BT DX
UMT/WG T 045 BT DX
UMT/WG T 067 BT DX
UMT/WG T 100 BT DX
Size
Power Suply
230V/1Ph+N+PE/50Hz
400V/3Ph+N+PE/50Hz
Recommended protection
Circuit Breaker
Circuit Breaker
Circuit Breaker
Circuit Breaker
C 16 A
C 25 A
C 25 A
C 20 A
MRA
13,9 A
20,7 A
20,4 A
19,9 A
P abs max
3190 W
4760 W
7065 W
9590 W
MRA = Maximum Rated Abs.
 Unit is made in accordance with EN-60204-1. All electrical cabling, in external unit, have been
made in accordance with EN-60204-1.
