BIKE OWNERS MANUAL
ENGLISH
ALLOY FRONT FRAMES:
Please fix the cable housings and the brake hose on the frame on the cable mounts
with cable zippers.
Please make sure to respect the 40mm distance between the cables and the BB
(bottom bracket) housing to avoid “ghost-shifting” and/or damages on the shift cables
and brake hoses.
For the rear brake please assemble the cable as shown in the following drawings:
Please keep in mind to have a minimum distance of 40mm between the brake hoses
and the BB housing as abovementioned!
The cable guide can be ordered via the Scott distribution with parts number:
223305 BB Cableguide Spark 2012

SCOTT SPARK Specifications

General

Suspension	Full Suspension
Wheel Size	29"
Rear Travel	120mm
Fork Travel	120mm
Fork	Fox 34 Float
Rear Shock	Fox Nude
Wheels	Syncros Silverton 2.0
Brakes	Shimano
Stem	Syncros
Saddle	Syncros
Seatpost	Syncros Duncan
Frame Material	Carbon
