SCOTT SPARK User Manual

SPARK
24 scott-sports.com 25
BIKE OWNERS MANUAL
ENGLISH
HEADSET OPTIONS BOTTOM BRACKET (BB) ON SPARK
Spark features different versions of headset systems.
1. A tapered headset and fork steerer system to match with semi-integrated headsets
of the “50-61”mm range with ID of Headtube of 44.0mm on top and 54.9mm on the
lower end.
All carbon front frames of Spark have a BB shell for BB92PF standard.
This matches to several bearing and crankset models of Shimano, SRAM, FSA and
others.
All alloy front frames of Spark have a BB shell for 73mm BSA standard.
It is also possible to use forks with a standard 1 1/8” steerer tube when using a reducer
headset such as e.g.
2. A straight 1 1/8” headset and fork steerer system to match with semi-integrated
headsets with an ID on the headtube of 44.0mm on top and lower end
This is a standard part in the market and should be available from several parts
manufacturers.
Ritchey WCS Carbon Zero Tapered PF 50-61mm 18mm UD PRD 13636
Ritchey PRO Tapered PF 50-61mm 12.9mm PRD 13640
Ritchey WCS Carbon Zero Tapered PF 50-61mm 18mm UD for 1 1/18 fork

SCOTT SPARK Specifications

General

Suspension	Full Suspension
Wheel Size	29"
Rear Travel	120mm
Fork Travel	120mm
Fork	Fox 34 Float
Rear Shock	Fox Nude
Wheels	Syncros Silverton 2.0
Brakes	Shimano
Stem	Syncros
Saddle	Syncros
Seatpost	Syncros Duncan
Frame Material	Carbon
