SCP SCIENCE DigiPREP Jr. User Manual

KeyPad service manual
Rev.1.1
44
9. Part lists
9.1 Controller major part list
SCP
number
Part Description
Manufacturer
Number
E296
Fuse, 0.5A, 250V, Fast blow, 1/4x1
1/4
AGC-1/2
E239
Voltage selector
83710030
E225
Switchcraft Panel Mt. 2 Pin Male
EN3P2M
E226
Switchcraft Cord, 2 Pin Female
EN3C2F
E287
Buzzer, Piezo
PKB24SPC-3601
E293
Diode, Rectifier, 1N400X
1N4002
E295
LED, Green
LN31GPHL
E305
Transistor,'NPN, 2N3904
2N3904
E310
Resistor, 22 ohm, 1Watt
RSF100JB-22R
E311
Resistor, 4.7k,c ohm, 1/8 w
CFR-12JB-4K7
E318
Switch, Tack,c Switch
TL1105LF160Q
E321
Transformer Dual 8vac 30a
3FD-316
E324
LCD Character Display
C-51505NFJ-SLW-
AC
E325
Voltage 'Regulator, 5Volt
UA7805KC
E326
Monostable multivibrator
MM74HC123AN
E329
CPU module
101-0383
E330
Solid State Relay, 240VAC, 25
amp
PF240D25
E331
Voltage regulator 5V 0.1A
LM78L05ACZ
E332
A/D Converter, 16 pin, dip
AD7705BN
E333
Crystal ,4.91520MHZ
MP042
E364
Battery,'3V, lithium battery
CR2354
E499
LED Blue
LNG901CFBW
E550
Power Cord Switch 15a
ABDWF150C0-831
