15
12. Limit switches
13. Control unit support
MECHANICAL INSTALLATION
Black = Limit switch
White = Slowdown start
Opening
Closing
Fig.21
Fig.22
Fig.24
JOINT
Fig.23
Sistemi Elettronici
di Apertura Porte e Cancelli
®
