SEA JOINT - Concrete Pad and Gate Attachment

7
Example of Colum standard installation
Fig.8
Out
In
50 mm
Hinge
Center
Out
In
Hinge
Center
50
mm
Anchor
wedge
4. Concrete pad and gate attachment
Above
Ground
Below
Ground
Concrete Pad
Fig.7
150
760
400
350
Example of Ground standard installation
MECHANICAL INSTALLATION
JOINT
Sistemi Elettronici
di Apertura Porte e Cancelli
®
Dimensions (mm)
