Figure 3 – Auxilary Unit Bolts
Aach with
provided bolts
and washers
3.) Disconnect power from Main Unit.
4.) Connect Wire Harness from the Entree Unit to the Main Unit. (Figure 4)
5.) Reconnect power to Main Unit.
Figure 4 – Wire Harnesses
IQ380 Aux Unit IQ380 Main Unit
Aux. Unit
Wire Harness
Light Harness
Light Harness
