EXTRA 260. Instruction Manual.
8
Wing bottom.
Thread.
Small weight.
Thread.
Small weight.
INSTALLING THE SWITCH.
Remove covering.
Switch.
Install the switch into the precut hole in the
side, in the fuselage.
Because the size of servos differ, you
may need to adjust the size of the precut open-
ing in the mount. The notch in the sides of
the mount allow the servo lead to pass through.
INSTALLING THE AILERON SERVOS.
We recommended to use long servos arm
( 70mm diameter) for all servos without throttle
servo.
Install the rubber grommets and brass
collets onto the aileron servo. Test fit the
servo into the aileron servo mount.
Using a small weight (
Weighted fuel pick-up
works well) and thread, feed the string through
the wing as indicated.
Rudder servo.
Throttle servo.
Servos.
Thread.
Small weight.
