www.seagullmodels.com
9
3x25mm.
Pushrod wire.
6) Attach the Z-Bend in the pushrod wire to
the throttle arm on the carburetor.
5) Bolt the engine to the engine mount using
the four machine screws. Double check that
all the screws are tight before proceeding.
Installing steering arm as below.
NOSE GEAR INSTALLATION.
2.5mm.
3x25mm.
112mm.
Adjust the nose gear steering arm until the
arm is parallel with the fire wall.
Steering arm.
Adjustable connector.
