Seagull Models ZERO MS:123 - Page 19

19
www.seagullmodels.com
8) A string has been provided in the wing to
pull the aileron lead through to the wing root.
Remove the string from the wing at the servo
location and use the tape to attach it to the
servo extension lead. Pull the lead through the
wing and remove the string.
M2x12mm.
M2x12mm.
Attach the string to the servo lead and
carefully thread it though the wing.
Flap servo.
Aileron servo.
Wing rib.
Small weight.
String.
Flap servo.
Aileron servo.
