3 SPECIFICATIONS
3.1 Identification
The machine identification label (example in Figure 4) is located at the bottom of the right-hand
cabinet, on the rear side of the machine.
This label indicates the model (version) and the power supply requirements.
CAUTION:
The mains supply must match the values indicated on the machine identification
label.
Figure 4: Machine identification label (example).
3.2 Machine dimensions
Uncrated: Metric American
Width 190.5 cm 75.0 in.
Height 132.6 cm 52.2 in.
Depth (excl. table) 47.7 cm 18.8 in.
Depth (incl. in-feed table) 55.0 cm 21.7 in.
Working height 90 cm 35.4 in.
Weight 232 kg 512 lbs
Crated:
Width 200 cm 78.7 in.
Height 162 cm 63.8 in.
Depth 90 cm 35.4 in.
Weight 270 kg 595 lbs
Working area:
Width 342 cm 135 in.
Depth 190 cm (75 in.) + 2x maximum board length
Note:
Anti-static clothing and footwear of the operator and an anti-static floor coating will help reduce
the build-up of electrostatic charges (ESD).
A relative humidity of at least 70% also helps reducing ESD-build-up.
