8 User Manual 54Base
1.3.3 On the machine
On the machine (See Figure 1) you will find the following warning symbols in black on a yellow
background.
ROTATING PARTS (1)
DANGER OF GETTING INJURED BY ROTATING PARTS.
MAKE SURE THAT THESE ROTATING PARTS DO NOT CATCH YOUR
FINGERS, CLOTHING, HAIR, ETC.
This symbol is placed on in-feed table arms and on the cabinets just above the output table (1).
ESD SHOCK (2)
DANGER OF GETTING AN ELECTRIC SHOCK CAUSED BY ELECTROSTATIC
CHARGE BUILD-UP IN THIS AREA.
This symbol is placed on those places where electrostatic charges can be build-up. The machine
parts close to the nip and the output material are most likely building up charges. Therefore ESD-
symbols are placed on the image guide (2)
Figure 1: Warning symbol locations.
