SEAL 62Base - Material Specifications; Machine Specifications; Optional Features

3.3 Material specifications
Maximum width: Metric American
Process up to 40°C (104 °F) – 62 Base 1600 mm 63 in.
- 54 Base 1400 mm 55.1 in.
Maximum roll diameter: (same both models)
Material unwind (upper unwind) 240 mm 9.4 in.
Material unwind (bottom unwind) 305 mm 1 ft.
Release liner wind-up 160 mm 6.3 in.
Maximum panel thickness: 50 mm 2.0 in.
Roll core inside diameter: 76.2 mm 3.0 in.
3.4 Machine specifications
Power ratings:
Europe 1N/PE 230VAC +/- 10%, 50/60Hz, 9.0A
USA - 62 Base 1N/PE 115VAC +/- 10%, 50/60Hz, 16.0A
- 54 Base 1N/PE 115VAC +/- 10%, 50/60Hz, 15.0A
(NEMA 5-20 plug supplied)
For the correct supply voltage version refer to the identification label on the machine.
Standard number of shaft positions:
Material unwind 2 (auto-grip)
Release liner wind-up 1
Nip setting: 0–52 mm 0 – 2.05 in.
Pressure: 0.3–1.0 N/mm 1.71 – 5.71 lbf/in.
Process speed:
Maximum 5 m/min 16.4 ft/min
Slow mode 0.9 m/min 3.0 ft/min
Maximum roller temperature: 40 °C 104 °F
Noise level <70 dB(A)
3.5 Optional features
The 54/62 Base “A” version has several options available. They are:
Item
Description
Part number
1
54 Base Infeed Trough Option
64619A
2
62 Base Infeed Trough Option
64614A
3
Leveling feet Option
5406A
4
54 Base Image Guide
64624A
5
62 Base Image Guide
64625A
6
Option 54 Base Lower Take-up W/ Plastic AutoGrip
64620
7
Option 62 Base Lower Take-up W/ Plastic AutoGrip
64618
8
POWER REAR TAKE UP OPTION 62 BASE
64623
Contact your sales representative or a customer service representative for more information.
Note: Some options may be included with your model.
