SEAL 62Base - Upper and Lower Section

Operation 15
English
3. Pull the film forward until approximately 10 cm (4 in.) is on the in-feed table.
If the film has a release liner:
 Peel off the release liner.
 Pull the release liner up and stick it to the tube on the wind-up position.
4. Stick the leader panel to the film and feed the panel into the nip using slow mode.
Note: Use a carrier board when processing thin images.
5.4.3 Upper and lower section
Figure 16: Upper and lower section webbed.
The film in the upper section is webbed first
1. Feed the film underneath (B) the splitter bar (between splitter bar and upper roller)
 Film without a release liner must be fed over the splitter bar (A).
2. Pull the film forward until it almost reaches the in-feed table and apply it to the upper roller.
If the film has a release liner (B):
 Peel off the release liner,
 Pull it up and stick it from below onto the tube on the wind-up position.
Now web the lower section
Figure 17: Webbing lower section.
3. Lift the in-feed table and put it in the upper position (A).
4. Unwind the film from the lower unwind roll.
5. Pull the film forward underneath the splitter bar until the end reaches above the nip and stick it to
the film from the upper section.
6. Lower the in-feed table.
